Ajax 12V PSU for Ajax Hub / Hub Plus / ReX 12V Low-voltage Power Supply Unit
- Use Ajax in premises lacking electricity or having an unstable power supply. A 12 V power supply unit allows connecting hubs and radio signal extenders to low-voltage networks or use a portable battery;
- Ajax protects your home, even if it goes on wheels. Connect the hub to a car or portable battery, and let the security system travel with you;
- Insert a SIM card and connect the hub to the on-board network or battery so that Ajax always guards your boat at the pier;
or you can request a price by email
Ajax 12V PSU for Ajax Hub / Hub Plus / ReX
A power supply unit, connecting Hub/Hub Plus control panels and ReX radio signal range extender to low-voltage power sources.
The power supply unit is compatible with Hub, Hub Plus, and ReX. It features a standard socket for connecting the power jack plug and has a bundled terminal adapter.
12V PSU is installed into the device body, replacing the pre-installed 110/230 V power supply unit.
|Dimensions||13.8 × 6.4 × 1.3 cm|
|Alarm Systems Type||
|Compatibility||Hub, Hub Plus, ReX|
|Input voltage||8-20 V DC|
|Output voltage||4.65 V ± 3%|
|Switch-on voltage||8 V ± 2.5%|
|Switch-off voltage||6.9-7.5 V (depending on load)|
|Input current||<1 А|
|Output current||1,5 А|
|Connection||Socket: 6,5 × 2 mm
Plug: 5,5 × 2,1 mm (power jack)
|Dimensions||138 × 64 × 13 mm|
|Complete set||12V PSU for Hub/Hub Plus/ReX
